特点
高效的传热由缠绕在选定云母带上的高质量镍铬电阻线提供并封装在模压成型的镀铝钢护套中。
非吸湿性云母绝缘材料确保了长期耐用性。
均匀配合±1/16英寸，因为低膨胀不锈钢夹紧带，确保至大热分布。
采用两件式结构，易于应用。每个加热器的额定电压为240V。串联480V；并联240V。
重型不锈钢接线端子配有硬件，旨在防止过度拧紧连接时的扭转。标准#10-32螺纹。
性能可靠，温度响应快
应用：
桶和模具、塑料成型机、挤出机、高压釜、加热管段数可达10-1/2“OD
订货信息：
| 型号 | Watts | Volts | W/in2 | Dimensions(inch) | Wt.(lb) | |
| Barrel Dia. | Heater Width | |||||
| MB3J1J2P1 | 500 | 240/480 | 30 | 3-1/2 | 1-1/2 | 0.7 |
| MB4A1J2P1 | 700 | 240/480 | 37 | 4 | 1-1/2 | 0.8 |
| MB4A2A2P1 | 800 | 240/480 | 32 | 4 | 2 | 0.8 |
| MB4J1J2P1 | 750 | 240/480 | 35 | 4-1/2 | 1-1/2 | 0.8 |
| MB4N1J2P1 | 600 | 240/480 | 27 | 4-3/4 | 1-1/2 | 0.8 |
| MB4Q1J2P1 | 900 | 240/480 | 39 | 4-7/8 | 1-1/2 | 0.8 |
| MB5A1J2P1 | 700 | 240/480 | 30 | 5 | 1-1/2 | 0.9 |
| MB5A1J2P2 | 900 | 240/480 | 38 | 5 | 1-1/2 | 0.9 |
| MB5E1J2P1 | 900 | 240/480 | 36 | 5-1/4 | 1-1/2 | 0.9 |
| MB5J1J2P1 | 800 | 240/480 | 31 | 5-1/2 | 1-1/2 | 0.9 |
| MB6A1J2P1 | 850 | 240/480 | 30 | 6 | 1-1/2 | 1 |
| MB6A1J2P2 | 1000 | 240/480 | 35 | 6 | 1-1/2 | 1 |
| MB6E1J2P1 | 750 | 240/480 | 25 | 6-1/4 | 1-1/2 | 1 |
| MB6J1J2P1 | 950 | 240/480 | 31 | 6-1/2 | 1-1/2 | 1 |
| MB6J1J2P2 | 1200 | 240/480 | 39 | 6-1/2 | 1-1/2 | 1 |
| MB6J2A2P1 | 1000 | 240/480 | 24 | 6-1/2 | 2 | 1 |
| MB6N1J2P1 | 1000 | 240/480 | 31 | 6-3/4 | 1-1/2 | 1 |
| MB7A1J2P1 | 1000 | 240/480 | 30 | 7 | 1-1/2 | 1.2 |
| MB7E1J2P1 | 1000 | 240/480 | 29 | 7-1/4 | 1-1/2 | 1.2 |
| MB7E2A2P1 | 900 | 240/480 | 20 | 7-1/4 | 2 | 1.3 |
| MB7G1J2P1 | 1200 | 240/480 | 35 | 7-3/8 | 1-1/2 | 1.2 |
| MB7J1J2P1 | 1000 | 240/480 | 28 | 7-1/2 | 1-1/2 | 1.2 |
| MB7J1J2P2 | 1200 | 240/480 | 34 | 7-1/2 | 1-1/2 | 1.2 |
| MB7N1J2P1 | 1000 | 240/480 | 27 | 7-3/4 | 1-1/2 | 1.2 |
| MB7Q1J2P1 | 1000 | 240/480 | 27 | 7-7/8 | 1-1/2 | 1.2 |
| MB8A1E2P1 | 1100 | 240/480 | 35 | 8 | 11/4 | 1.4 |
| MB8A1J2P1 | 1000 | 240/480 | 27 | 8 | 1-1/2 | 1.4 |
| MB8A1J2P2 | 1300 | 240/480 | 35 | 8 | 1-1/2 | 1.4 |
| MB8J1J2P1 | 1200 | 240/480 | 30 | 8-1/2 | 1-1/2 | 1.5 |
| MB8J1J2P2 | 1400 | 240/480 | 35 | 8-1/2 | 1-1/2 | 1.5 |
| MB8J2A2P1 | 1600 | 240/480 | 30 | 8-1/2 | 2 | 1.5 |
| MB9A1J2P1 | 1300 | 240/480 | 31 | 9 | 1-1/2 | 1.6 |
| MB9A1J2P2 | 1500 | 240/480 | 35 | 9 | 1-1/2 | 1.6 |
| MB9J2A2P1 | 1800 | 240/480 | 30 | 9-1/2 | 2 | 1.7 |
| MB9N2A2P1 | 2000 | 240/480 | 33 | 9-3/4 | 2 | 1.8 |
| MB10A1J2P1 | 1000 | 240/480 | 21 | 10 | 1-1/2 | 2.1 |
| MB10A1J2P2 | 1400 | 240/480 | 30 | 10 | 1-1/2 | 2.1 |
| MB10J1J2P1 | 2000 | 240/480 | 40 | 10-1/2 | 1-1/2 | 2.4 |
