SV4100和SV4300系列是直动式电磁阀。阀门采用黄铜阀体，带有黄铜和不锈钢接液部件以及FKM密封材料。该阀门的温度范围为-10至137℃（14至280℉），非常适合中性介质，如压缩空气、惰性气体、水和合成油。每个单元都配有一个应力消除连接器。还提供1/2“导管插头。
规格
安装位置：任何（至好是电磁阀系统直立）
至高工艺温度：137℃（280℉），采用FKM O型圈
至高环境温度：取决于线圈（参见线圈的额定值）
电压容差：±10%
开启时间：
交流电：约8至15毫秒
直流电：约10至20毫秒
闭合时间：
AC：约8至15毫秒
DC：约10至20毫秒
循环速率：约1000份/分钟
占空比：连续（100%）
结构材料
| Body | Brass |
| Armature Tube | Stainless Steel 300 |
| Fixed Core | Stainless Steel 400 |
| Plunger | Stainless Steel 400 |
| Spring | Stainless Steel 300 |
| Shading Ring | Copper |
| Orifice | Brass |
线圈规格
| Coil | Inrush VA | Holding VA |
| 8 W | 25 | 14 |
订货信息：
| 3路通用常开型号 | Pipe Sizet | Orifice Size | 3rd Way Exhaust Orifice | Cv Flow Factor | Coil Power | Minimum psi | Operating Pressure | |
| M.O.P.D.* | ||||||||
| AC | DC | |||||||
| SV4101 | 1/8" | 3/64" | 3/32" | 0.06 | 8W | 0 | 260 | 260 |
| SV4102 | 1/8" | 1/16" | 1/16" | 0.1 | 8W | 0 | 145 | 145 |
| SV4103 | 1/8" | 3/32" | 3/32" | 0.22 | 8W | 0 | 60 | 60 |
| SV4104 | 1/8" | 1/8" | 1/8" | 0.28 | 8W | 0 | 50 | 50 |
| SV4105 | 1/4" | 3/64" | 3/64" | 0.06 | 8W | 0 | 260 | 260 |
| SV4106 | 1/4" | 1/16" | 1/16" | 0.1 | 8W | 0 | 145 | 145 |
| SV4107 | 1/4" | 3/32" | 3/32" | 0.22 | 8W | 0 | 60 | 60 |
| SV4108 | 1/4" | 1/8" | 1/8" | 0.28 | 8W | 0 | 50 | 50 |
| 常闭型号 | ||||||||
| SV4301 | 1/8" | 3/64" | 3/32" | 0.06 | 8W | 0 | 290 | 290 |
| SV4302 | 1/8" | 1/16" | 3/32" | 0.1 | 8W | 0 | 215 | 215 |
| SV4303 | 1/8" | 5/64" | 3/32" | 0.14 | 8W | 0 | 145 | 145 |
| SV4304 | 1/8" | 3/32" | 3/32" | 0.22 | 8W | 0 | 85 | 85 |
| SV4305 | 1/8" | 1/8" | 3/32" | 0.28 | 8W | 0 | 70 | 70 |
| SV4306 | 1/4" | 3/64" | 3/32" | 0.06 | 8W | 0 | 290 | 290 |
| SV4307 | 1/4" | 1/16" | 3/32" | 0.1 | 8W | 0 | 215 | 215 |
| SV4308 | 1/4" | 5/64" | 3/32" | 0.14 | 8W | 0 | 145 | 145 |
| SV4309 | 1/4" | 3/32" | 3/32" | 0.22 | 8W | 0 | 85 | 85 |
| SV4310 | 1/4" | 1/8" | 3/32" | 0.28 | 8W | 0 | 70 | 70 |
| 配件 | ||||||||
| Connectors (NEMA 4) | ||||||||
| SV-CGC | Replacement cable grip connector | |||||||
| SV-CC | ¹/₂" conduit connector | |||||||
| Coils | ||||||||
| SV8COIL-115AC | Replacement 8 W coil for 110 to 120 Vac/50 to 60 Hz 154℃ (310℉) (Class F) | |||||||
| SV8COIL-12DC | 8 W coil for 12 Vdc 154℃ (310℉) (Class F) | |||||||
| SV8COIL-24DC | 8 W coil for 24 Vdc 154℃ (310℉) (Class F) | |||||||
| SV8COIL-24AC/60HZ | 8 W coil for 24 Vac/60Hz 182℃ (360℉) (Class H) | |||||||
| SV8COIL-220AC | 8 W coil for 220 to 240/50 to 60 Hz 154℃ (310℉) (Class F) | |||||||
| SV8COIL-115/60HZ | 8 W coil for 115/60 Hz 182℃ (360℉) (Class H) | |||||||
*至大工作压差
BSP连接在大多数情况下，这种尺寸的BSP和NPT是可以互换的
配有操作手册和电缆手柄连接器
