特点：
Incoloy®护套
1600 to 3950 Watts
120,208,240,275 and 480 Volt
40 W/in2
2-3/4"冷端
870℃(1600℉)至大护套温度
辐射加热器部件(DU-RAD型)
应用程序
室内环境辐射供暖、加热高速空气、低温夹具
优点
特别构造，在辐射采暖应用中提供出色的使用寿命。
特点
类型3端子：电弧焊到冷针上。请参阅管形加热器概述部分中的端子详图。
扣环定位辐射加热器组件中的元件。
弯曲：仅纵向弯曲。参见管形加热器概述部分中的弯曲要求。
订货信息：
| INCOLOY Sheath 型号 | G-DIM In.(cm) | Watts | Volts | W/In2 | 重量 (Lb.) |
| UTU-40/120 | 18-5/16(47) | 1600 | 120 | 40 | 1 |
| UTU-40V/208 | 18-5/16(47) | 1600 | 208 | 40 | 1 |
| UTU-40/240 | 18-5/16(47) | 1600 | 240 | 40 | 1 |
| UTU-40V/275 | 18-5/16(47) | 1600 | 275 | 40 | 1 |
| UTU-48/120 | 22-3/16(56) | 1970 | 120 | 40 | 1 |
| UTU-48V/208 | 22-13/16(56) | 1970 | 208 | 40 | 1 |
| UTU-48/240 | 22-13/16(56) | 1970 | 240 | 40 | 1 |
| UTU-48V/275 | 22-13/16(56) | 1970 | 275 | 40 | 1 |
| UTU-58/120 | 27-3/16(69) | 2440 | 120 | 40 | 2 |
| UTU-58V/208 | 27-13/16(69) | 2440 | 208 | 40 | 2 |
| UTU-58/240 | 27-13/16(69) | 2440 | 240 | 40 | 2 |
| UTU-58V/275 | 27-13/16(69) | 2440 | 275 | 40 | 2 |
| UTU-58/480 | 27-13/16(69) | 2440 | 480 | 40 | 2 |
| UTU-66/120 | 31-13/16(81) | 2820 | 120 | 40 | 2 |
| UTU-66V/208 | 31-13/16(81) | 2820 | 208 | 40 | 2 |
| UTU-66/240 | 31-13/16(81) | 2820 | 240 | 40 | 2 |
| UTU-66V/275 | 31-13/16(81) | 2820 | 275 | 40 | 2 |
| UTU-66/480 | 31-13/16(81) | 2820 | 480 | 40 | 2 |
| UTU-74/120 | 35-13/16(91) | 3190 | 120 | 40 | 2 |
| UTU-74V/208 | 35-13/16(91) | 3190 | 208 | 40 | 2 |
| UTU-74/240 | 35-13/16(91) | 3190 | 240 | 40 | 2 |
| UTU-74V/275 | 35-13/16(91) | 3190 | 275 | 40 | 2 |
| UTU-74/480 | 35-13/16(91) | 3190 | 480 | 40 | 2 |
| UTU-82V/208 | 39-7/8(101) | 3570 | 208 | 40 | 2 |
| UTU-82/240 | 39-7/8(101) | 3570 | 240 | 40 | 2 |
| UTU-82V/275 | 39-7/8(101) | 3570 | 275 | 40 | 2 |
| UTU-82/480 | 39-7/8(101) | 3570 | 480 | 40 | 2 |
| UTU-90V/208 | 43-7/8(111) | 3950 | 208 | 40 | 2 |
| UTU-90/240 | 43-7/8(111) | 3950 | 240 | 40 | 2 |
| UTU-90V/275 | 43-7/8(111) | 3950 | 275 | 40 | 2 |
| UTU-90/480 | 43-7/8(111) | 3950 | 480 | 40 | 2 |
| UTU-102V/208 | 49-7/8(127) | 4520 | 208 | 40 | 2 |
| UTU-102/240 | 49-7/8(127) | 4520 | 240 | 40 | 2 |
| UTU-102V/275 | 49-7/8(127) | 4520 | 275 | 40 | 2 |
| UTU-102/480 | 49-7/8(127) | 4520 | 480 | 40 | 2 |
| UTU-112V/208 | 54-7/8(139) | 4990 | 208 | 40 | 3 |
| UTU-112/240 | 54-7/8(139) | 4990 | 240 | 40 | 3 |
| UTU-112V/275 | 54-7/8(139) | 4990 | 275 | 40 | 3 |
| UTU-112/480 | 54-7/8(139) | 4990 | 480 | 40 | 3 |
| UTU-124V/208 | 60-15/16(155) | 5560 | 208 | 40 | 3 |
| UTU-124/240 | 60-15/16(155) | 5560 | 240 | 40 | 3 |
| UTU-124V/275 | 60-15/16(155) | 5560 | 275 | 40 | 3 |
| UTU-124/480 | 60-15/16(155) | 5560 | 480 | 40 | 3 |
| UTU-136V/208 | 66-15/16(170) | 6130 | 208 | 40 | 3 |
| UTU-136/240 | 66-15/16(170) | 6130 | 240 | 40 | 3 |
| UTU-136V/275 | 66-15/16(170) | 6130 | 275 | 40 | 3 |
| UTU-136/480 | 66-15/16(170) | 6130 | 480 | 40 | 3 |
| UTU-148V/208 | 72-15/16(185) | 6700 | 208 | 40 | 4 |
| UTU-148/240 | 72-15/16(185) | 6700 | 240 | 40 | 4 |
| UTU-148V/275 | 72-15/16(185) | 6700 | 275 | 40 | 4 |
| UTU-148/480 | 72-15/16(185) | 6700 | 480 | 40 | 4 |
| UTU-156V/208 | 77(196) | 7100 | 208 | 40 | 4 |
| UTU-156/240 | 77(196) | 7100 | 240 | 40 | 4 |
| UTU-156V/275 | 77(196) | 7100 | 275 | 40 | 4 |
| UTU-156/480 | 77(196) | 7100 | 480 | 40 | 4 |
| UTU-164/240 | 81(206) | 7450 | 240 | 40 | 4 |
| UTU-164V/275 | 81(206) | 7450 | 275 | 40 | 4 |
| UTU-164/480 | 81(206) | 7450 | 480 | 40 | 4 |
| UTU-172V/208 | 85-1/16(216) | 7830 | 208 | 40 | 5 |
| UTU-172/240 | 85-1/16(216) | 7830 | 240 | 40 | 5 |
| UTU-172V/275 | 85-1/16(216) | 7830 | 275 | 40 | 5 |
| UTU-172/480 | 85-1/16(216) | 7830 | 480 | 40 | 5 |
